0927 Series 2/2 Way Electric Solenoid Diaphragm Valve
Maximum working pressure:1.6MPa
Automatic; free maintenance; Waterproof(IP65), Shake-proof, Energy-saving, Environment-friendly; Forging brass valve, Easy installation;
Working Voltage:AC 220V Port
1.Specification
Maximum working pressure:1.6MPa
Automatic; free maintenance;
Waterproof(IP65), Shake-proof, Energy-saving, Environment-friendly;
Forging brass valve,
Easy installation;
Working Voltage:AC 220V
Port Size:G3/4''
Weight: 800g
2.Dimensions
MODEL | 0927000 | 0927200 | 0927300 | 0927400 | 0927500 | 0927600 | 0927700 |
PORT SIZE | G1/4'' | G1/2'' | G3/4'' | G1'' | G 1 1/4'' | G1 1/2'' | G2'' |
BORE(mm) | 8 | 12 | 20 | 25 | 32 | 40 | 50 |
KV VALUE | 1.15 | 1.70 | 5.1 | 5.35 | 20.0 | 25.0 | 43.0 |
WEIGHT(kg) | 0.70 | 0.70 | 1.20 | 1.30 | 2.70 | 2.70 | 3.50 |
PRESSURE | 0.07~1.6MPa | 0.1~1.6MPa | |||||
MEDIUM | AIR,WATER(OIL,STEAM) | ||||||
TYPE | NORMAL CLOSED | ||||||
BODY MATERIAL | BRASS | ||||||
SEAL MATERIAL | NBR/VITON(SILICAL) | ||||||
TEMPERATURE | NBR:-5~80C (VITON:-20~150C) | ||||||
COIL | 0200 DIN43650A | ||||||
SMART PNEUMATIC CO LTD belongs to HUAHUI GROUP CHINA, which is specialized in manufacturing all kinds of hydropneumatic components, aluminum parts and plastic parts. Our main products are including pneumatic cylinder, (air cylinder), solenoid valve, air filter, air regulator, air lubricator, pneumatic fitting, hydraulic fitting, tubes, muffler (silencer) etc.
SMART PNEUMATIC take the lead in passing ISO9001 quality system certification and UKAS system certification in this industry and equip with a complete set equipment (CNC machine, data control lathe, and all kinds of testing machines) and checkout system. Under the joint effort of all our members, SMART PNEUMATIC has already established a strong foundation today.
SMART PNEUMATICS' sprit is to give you the best quality, the competitive price, the quick delivery, the perfect service. Our goal to customers is "Always Smart Solution for your Automatic System."
SMART PNEUMATIC believes our profession and efficiency will make your international business easier and quicker.
SMART PNEUMATIC hopes to work together with you, developing in parallel!
