How to adjust the cylinder with adjustable stroke
May 19, 2021
How to adjust the cylinder with adjustable stroke
1. First, determine whether the cylinder is adjustable stroke, if it is directly adjustable screw or nut;
2. The stroke of the cylinder can be reduced by installing a sleeve on the cylinder shaft;
3. Install the travel switch to control the solenoid valve and adjust the travel at will;
4. Some cylinders have magnetism inside, and a matching magnetic switch is installed outside to control the solenoid valve and stroke;
5. The stroke can be changed by mechanical lever mechanism
6. You can buy adjustable stroke cylinder, the general adjustment range is 50 mm, of course, you can also make a longer adjustment range. For the installed cylinder, the adjusting element can be installed on the piston rod, but only the retraction stroke can be adjusted.
